Medisana IN 515 Ultrasonic inhaler
Portable ultrasonic nebulizer IN 515
Technical data
Name and model: medisana portable ultrasonic nebulizer IN 515 (model: NBM-1)
Power: 3 V, 2 x 1, 5 V batteries AA LR6 or 5 V / 1 A (via USB-C)
Energy consumption: < 2VA
Power consumption in standby mode: < 0.1mA
Ultrasonic frequency: 110 kHz ±10 kHz
Nebulization capacity: >0.2 ml/minute
Particle size (MMAD): <5μm
Percentage of particles that penetrate deep into the lungs as a fine mist: ≥60%
Types of liquid nebulizers: solution and suspension
Position in which the nebulizer works optimally: vertical
Maximum amount of inhalant: 10 ml
Automatically switches off after 20 minutes
Operating conditions: +10 °C - +40 °C, relative humidity 10-95%, air pressure 86-106 kPa
Storage conditions: -20 °C - +70 °C, relative humidity 10-95%, atmospheric pressure 50-106 kPa
Weight approx.: 108 g (without batteries)
Product life: 3 years
Item No.: 54590
EAN number: 40 15588 54590 0
Spare parts: art. 54591 mask for children for IN 515, EAN 40 15588 54591 7
art. 54592 mask for adults for IN 515, EAN 40 15588 54592 4
art. 54593 mouthpiece for IN 515, EAN 40 15588 54593 1
What is this medicine used for?
Breathe allergy-free with medisana's compact, quiet & portable inhaler against pollen, house dust & more
Directions for use
Usage: Restore power supply
To use the medisana ultrasonic nebulizer IN 515 it can be powered by 2 x 1.5 AA batteries
V or using the USB-C cable.
a) Battery power supply:
Open the battery compartment cover 7 on the bottom of the device in the direction of the arrow (see figure). Insert the
2 batteries included (type AA/LR6 1.5 V). Make sure the batteries are inserted in the correct direction. Connect
the battery compartment cover 7 again. Replace the batteries with new ones as soon as possible if the device is switched on.
indicator light 3 orange flashes.
b) Power supply using the USB-C cable:
Open the cover of the USB-C connector 1 and connect the USB-C cable to a suitable
power source. This device cannot be used to charge rechargeable batteries.
Preparation for use
1. Make sure the appliance is switched off.
2. Open the reservoir valve 5 and fill it with the inhaler (maximum capacity 10 ml = 10 ccm). Carefully read the instructions for use and dosage on the package insert of the medication you are using.
3. Close the reservoir cover 5 again. Check that the reservoir 5 is positioned correctly and hold the appliance upright.
possible to prevent it from leaking.
Inhale through the mouthpiece
1. Sit up as straight as you can.
2. Place the mouthpiece 4 on the device and close your lips completely around it.
3. Turn on the appliance by pressing the on/off button 2. The indicator light 3 lights up green.
4. Now breathe in slowly and deeply through your mouth and out through your nose. You can improve the effectiveness of the therapy by
inhale to hold the air briefly. However, this is not necessary for a general result of the therapy. It is important
that you remain calm and relaxed while breathing in and out evenly. Do not inhale too quickly. If you wish, you can take a short breath.
pause and remove the mouthpiece 4 from your mouth. Put it back in your mouth (lips completely enclose it) and breathe in
slowly in and out again.
INSTRUCTIONS
• Keep the appliance upright as much as possible. However, if it is tilted slightly, this will not have any
influence on use. For optimal operation, make sure you hold the device as straight as possible while inhaling.
keeps possible.
• Move the device slightly when the amount of aerosol is almost used up, so that the remaining amount is better distributed.
is distributed over the membrane.
5. A treatment should not last longer than 20 minutes.
6. When the reservoir 5 is empty, the indicator light 3 lights up red and the appliance switches off shortly afterwards. You can
After inhaling, you can also switch it off manually by pressing the on/off button 2, even if all the inhalant has been used.
has not yet been used up.
7. Pour any remaining inhalant from the reservoir. Do not reuse it. Always clean the device immediately after use.
clean. (See also "Cleaning and maintenance" and "Disinfection".) If the nozzle 4 is in use for a long time,
During use, 2-3 drops of inhalant may appear in the mouthpiece tube. However, this does not affect
on the use and operation of the device. Remove drops with a soft cloth after use.
Inhaling with the mask
An adult mask and a child mask are also included, which allow the aerosol to be expelled through the nose.
are inhaled. Older people in particular find this application more pleasant.
To inhale with the mask, the adult or child mask should be placed 4 inches on the outlet of the reservoir.
are placed. Then follow the directions as described in "Inhaling with the mouthpiece". The difference is that the mouth
does not close around the mouthpiece, but that the mask is held over the mouth and nose.
Cleaning and maintenance
• Remove the mask or mouthpiece from the device and pour out any remaining inhalant.
• Never hold the entire device or the nebulizer unit under running water for cleaning and ensure that no water gets into it.
the device arrives.
• Start the cleaning mode of the device as follows: make sure the device is switched off and add 3-6 ml of clean water
in the reservoir 5. Activate the cleaning mode by pressing the on/off button 2 for 3 seconds. The
Indicator light 3 flashes green slowly. Cleaning mode lasts for 3 minutes, and the device then exits this mode.
by switching off automatically.
• Now disconnect the power supply (remove batteries and/or disconnect the USB-C cable).
• Press the release button 6 on the back of the appliance and remove the reservoir 5.
• Rinse the inside of the reservoir 5 with clean water for at least 3 minutes. Do not rinse the
bottom of the cup, see image.
• You can clean the housing of the device with a cloth slightly dampened in water.
a mild cleaning agent.
• Clean the mask or mouthpiece under running water.
• Then allow all parts to air dry thoroughly on a dry, soft surface (e.g. a
towel).
• If the appliance has not been used for a long period of time and before using it for the first time,
can also be cleaned in this way.
Disinfect
In case of infectious diseases, in addition to cleaning the device, you should also disinfect it by performing the following
steps. We recommend that you perform the following actions regularly in the morning or evening.
to be carried out at a fixed time in the evening:
• Rinse the mask(s) and mouthpiece with distilled water.
• Bring distilled water to the boil in a saucepan.
• Place the mouthpiece in the boiling water for 5 minutes.
• Then remove the parts from the water and leave them in the air (e.g. lying on a
towel) dry and cool.
• Instead of boiling distilled water, you can also soak the parts in a solution of
75% cleaning alcohol - they only need to sit in there for 1 minute.
Then rinse the parts with distilled water and let them air dry.
• Ensure that no residue of the disinfectant remains on the parts, as this would
could otherwise pose a hazard the next time the appliance is used.
used.
Troubleshooting
Problem: little/no atomization
Solution: Replace the batteries or check whether the power supply is working properly. Check whether the reservoir 5 is correctly positioned on the
Check that the device is assembled and that there is sufficient aerosol in the reservoir. Clean the device.
Problem: Indicator light 3 flashes green and then turns off
Solution: The device has been in use for a long time. Turn off the device and wait a few minutes before turning it on again.
used.
Problem: Indicator light 3 flashes red and then turns off
Solution: reservoir 5 empty or insufficient voltage.
Problem: Indicator light 3 flashes orange and then turns off
Solution: Replace the batteries or connect the USB-C cable correctly and ensure there is sufficient aerosol in reservoir 5.
If the above instructions do not solve the problem, please contact customer service.
Electromagnetic compatibility
The device complies with the requirements of the EN 60601-1-2 standard for electromagnetic compatibility. Details
You can find more information about these measurements in the product information sheet.
Ingredients
Inhaler
Warnings
Safety instructions
• When using an electronic device, basic safety precautions should always be followed, including the following instructions.
• Use the appliance only for its intended purpose, as described in the user manual. Using it for any other purpose will void the warranty.
• Any use other than that described above is considered improper and dangerous. If the appliance is not used as intended, responsibility for its safe operation transfers to the user.
• Use only original (spare) parts from the manufacturer.
• Use only liquid medications suitable for inhalation therapy. Consult your doctor or pharmacist about the duration, dosage, frequency of use, and choice of medications before starting therapy with the device.
• When this device is used by children or people with disabilities, close supervision is necessary. The dosage and frequency of use should also be determined by the prescribing physician.
• Do not use the appliance under a blanket or pillow. Excessive heat can cause fire, electric shock, or personal injury.
• Follow the doctor's advice regarding the duration of treatment and take the medications recommended by the doctor.
• Do not insert your finger or any object (e.g. cotton swab, etc.) into the opening of the device – risk of damage!
• Do not repair the appliance yourself if it is defective. Have repairs carried out only by an authorized service center.
• Do not open or modify the appliance.
• This device is not suitable for use in an anaesthesia or ventilation device.
Before use
• The device is designed for use in an environment that meets the conditions as described in the technical
data. Make sure you adhere to it.
• Do not use the appliance if it is damaged or has fallen into water, but contact customer service.
or send it in for repair.
• Check that all parts are clean and disinfected. To prevent the risk of infection, follow the instructions and clean
the appliance and its parts as described in the chapter "Cleaning and Care" or "Disinfection".
• The reservoir 5 can be filled with a maximum of 10 ml. Never fill the reservoir beyond the marked maximum.
• To prevent bacterial infection, never use the mouthpiece, adult mask and child mask with
Multiple people. Each user must use their own mask or mouthpiece.
During use
• Never switch on the appliance if there is no aerosol in the reservoir 5.
• Keep the appliance balanced and steady during use to avoid spills.
• Do not open the reservoir lid during use.
• Stop use immediately and consult your doctor if you experience any complaints during use.
• This appliance has a timer that automatically switches off after 20 minutes. Every time the appliance is switched on
restart this timer.
• If the timer runs out or the appliance switches off due to another problem (e.g. insufficient power voltage,
(If the aerosol is on) the indicator light 3 will light up red.
After use
• Clean or disinfect the device and its parts as described in the chapter "Cleaning and maintenance" or.
"Disinfecting" in these instructions. Failure to follow these instructions may result in infections such as
result of the growth of microorganisms.
• Do not store the device or its parts where they will be exposed to direct sunlight, heat or moisture.
• The appliance and its parts must not be cleaned in the dishwasher or dried in the microwave.
• Always keep the appliance out of reach of children.
BATTERY SAFETY INSTRUCTIONS
• Do not take batteries apart!
• Remove low batteries from the battery compartment immediately as they may leak and damage the device.
damage!
• Increased risk of leakage, avoid contact with skin, eyes and mucous membranes! In case of contact with battery acid, rinse the
Immediately flush the affected area with plenty of clean water and consult a doctor immediately!
• Consult a doctor immediately if a battery has been swallowed!
• Always replace all batteries at the same time!
• Only insert batteries of the same type, do not use different types or used and new batteries together!
• Insert the batteries correctly, paying attention to the polarity!
• Remove the batteries if you do not intend to use the device for at least 3 months.
• Keep batteries away from children!
• Do not recharge the batteries! There is a risk of explosion!
• Do not short circuit! There is a risk of explosion!
• Do not throw into an open fire! There is a risk of explosion!
• Do not throw used batteries and accumulators into the household waste, but collect them separately or hand them in at a shop where batteries are recycled.
are sold!
Storage advice
Store the appliance and all parts in a dry and clean place.
• Make sure that there are no liquids left in reservoir 5 during transport and storage.
• Remove the batteries if the device is not going to be used for a long period of time.
• Do not store in places exposed to direct sunlight, extreme temperatures and high
humidity.
• Always keep the appliance away from fire, electromagnetic radiation and children.
Other information
Medical device. Read the instructions for use before use.
Manufacturer / Distributor
medisana GmbH,
Carl-Schurz-Str. 2, ,
41460 NEUSS, ,
Germany
